| 1D | All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Codabar,UCC/EAN 128, RSS, ITF, ITF-14, ITF6, Standard 25, Matrix 25,COOP 25, Industrial 25, Plessey, MSI Plessey, Code 11, Code93, Code 49, Code 16K. |
| 2D | All major 2D symbologies, including PDF417, QR Code, Data Matrix, AZTEC, CSC, Maxicode,Micro QR, Micro PDF417, GM , Code One. |
| Image Sensor | CMOS 1280 * 800 |
| Aiming | 650nm Laser diode or 518nm green LED |
| Illumination | White LED |
| Scan Modes | Sense mode, Continuous mode, Level mode, Pulse mode |
| Scan Rate | 60 frames per second |
| Depth of Field EAN 13 (13mil) | 55-360mm |
| Depth of Field Code 39 (5mil) | 70-180mm |
| Depth of Field PDF417 (6.67mil) | 55-160mm |
| Depth of Field DataMatrix (10mil) | 50-170mm |
| Depth of Field QR (15mil) | 40-210mm |
| Field of View Horizontal | 51° |
| Field of View Vertical | 32° |
| Scan Angle Roll | 360° |
| Scan Angle Pitch | ±55° |
| Scan Angle Skew | ±55° |
| Minimal Print Contrast | 25% |
| Processor | 1GHz,X1500 |
| Current @ 5VDC Operating | 276.8mA (typical), 322.7mA (max.) |
| Current @ 5VDC Standby | 83.3mA |
| Dimensions (mm) | 41.5(W)×49.5(D)×24.3(H)mm |
| Input Voltage | 5VDC±5% |
| Interfaces | RS-232, USB |
| Material | PC,ABS |
| Notifications | Beep, LED indicator |
| Power Supply Input | DC5V, 1.5A |
| Power Supply Output | AC100~240V, 50~60Hz |
| Weight | 75g |
| Operating Temperature | -20℃ to 60℃ (-4°F to 140°F) |
| Storage Temperature | -40℃ to 70℃ (-40°F to 158°F) |
| Humidity | 5%~95% (non-condensing) |
| Electro Static Discharge (ESD) | ±14 kV (air discharge), ±8 kV (direct discharge) |
| Drop | 1.5m |
| IP Rating | IP54 |
| Configuration Tools | EasySet |
| Hardware | FCC Part15 Class B, CE EMC Class B, RoHS, IEC60825, IEC62471, KC |
